Model

ALMI 20

Source

Multi diode (Fiber IPG)

Laser output power

20W

Laser wave length

1064nm

Q-Switch frequency of laser

20kHz  ~ 80 kHz

Marking area

70mm × 70mm (optional)

Minimum character size

0.5mm

Minimum line width

0.01mm

Marking depth

≤ 0.2mm

Beam quality m2

< 1.1

Marking speed

600 – 1000 Characters

Total power

500W

Electricity

230V AC 50/60Hz

Cooling system

System dimensions (L X W X H)

Air cooling

Size of the host system

800mm × 680mm × 1200mm
